G8RD Series Digital Load Cell for Truck Scales
The G8RD series digital load cell represents the most modern technology in the field of truck scales and high-capacity industrial weighing. It is specifically designed to achieve the highest levels of precision, reliability, and durability, taking into account the details that form the basis of excellent performance.
The load cell's digital system manages internal calculations in real time, ensuring fast and accurate data processing. The system configuration and update are performed via a serial interface, which allows for simple and efficient maintenance.
Key Features and Advantages
A G8RD mérőcellák tervezésénél a hangsúly a precizitáson és az erőn van. Szakértőink minden részletre odafigyeltek a maximális cellateljesítmény elérése érdekében, ami elengedhetetlen a hitelesített mérésekhez.
- Real-Time Internal Calculations: The built-in digital system processes the load data instantly, minimizing latency and increasing measurement stability.
- Serial Interface: Enables simple and reliable software update and configuration.
- Excellent Protection: IP69K protection class, which guarantees dust and water resistance even during high-pressure cleaning.
- Jogi Alkalmasság: A mérőcellák alkalmasak hitelesített kereskedelmi alkalmazásokhoz, megfelelve a szigorú OIML előírásoknak.
- Robust Design: The use of stainless steel material ensures long life and corrosion resistance, even in harsh industrial environments.
Technical Specifications
The G8RD series offers solutions across a wide range of load capacity and precision, from 18 tons up to 50 tons.
| Capacity (In) [t] |
Accuracy Class (OIML) |
Minimum Division (vmin) |
Material |
IP Protection |
Jogi Mérésügyi |
| 18 |
C4 |
15000 |
Stainless steel |
IP69K |
Suitable for |
| 30 |
C4 |
15000 |
Stainless steel |
IP69K |
Suitable for |
| 40 |
C4 |
15000 |
Stainless steel |
IP69K |
Suitable for |
| 50 |
C4 |
15000 |
Stainless steel |
IP69K |
Suitable for |
Further Technical Parameters:
- Névleges terhelés (I_n): 18 t, 30 t, 40 t, 50 t (model dependent)
- Pontossági Osztály (Y): Y = emax / vmin (Az OIML szabvány szerinti meghatározás)
- Design: Load cell for truck scales.
- Configuration: Also recommended for industrial installations, silos, and high-capacity tanks.
Additional Digital Systems
The performance of G8RD load cells can be supplemented with digital displays and junction boxes that take advantage of the cell's advanced digital capabilities.
Junction Box
- GBOX8D: This junction box ensures reliable communication connection between the digital load cells and serves as the system's central point.
Digitális Kijelzők
The digital system enables individual control over every single truck scale cell, maximizing system accuracy and diagnostics.
GI430D – Approved Digital Indicator
- Function: Approved indicator for digital cells.
- Advantage: Digital system that enables individual control and monitoring of all truck scale cells.
GI650D – Touch Screen Display
- Function: Touch screen display for weighing truck scales with digital cells.
- System: Capable of providing custom solutions for managing all load cells of the truck scale.
GI650D ABS – Robust Touch Screen Display
- Configuration: Touch screen display with an ABS housing, ensuring enhanced mechanical resistance.
- Firmware: Speciális firmware -rel rendelkezik a tehergépjármű-méréshez és a hídmérlegek menedzseléséhez.
The Importance of Details in Manufacturing
„Every detail has value” – this philosophy guides the manufacturing of the G8RD series. Precise manufacturing processes guarantee that every single load cell meets the highest quality and performance requirements. The result of careful design and execution is an extremely stable and long-lasting measuring device, ideal for the most demanding industrial and commercial applications.
The G8RD series digital load cells are the ideal choice for industrial stakeholders looking for a reliable, high-capacity, and legally certifiable measuring solution for their truck scales. The integration of digital technology ensures a future-proof system that is easy to maintain and scalable.
