BEP Series Floor Scale – Low Profile, High Capacity Weighing Solution

The BEP series floor scale is a robust and precise weighing platform specifically designed for industrial environments requiring high load capacity and reliable measurement. This model stands out due to its extremely low profile, which significantly facilitates the loading and unloading of pallets, containers, and other large objects.

Key Features and Advantages

The BEP platform has been designed with efficiency and ease of handling in mind:

• Extremely Low Profile: The platform's design minimizes the need for ramps or lifting equipment, thereby making the weighing process faster and safer.
• Négy Terhelésérzékelő: The four-point load cell system guarantees excellent accuracy and stability even in cases of load eccentricity, ensuring reliable measurement across the entire weighing range.
• Easy Access: Thanks to the low profile, access to the platform is extremely easy, making it ideal for logistics and production areas that require frequent weighing.
• Beépített Szintező: The built-in water level (bubble level) ensures that the scale always stands on a perfectly horizontal surface, which is essential for maintaining weighing accuracy.
• Compatibility with Multifunction Indicators: The platform can be paired with GI400 and GI410 series multifunction displays (indicators) which offer a wide range of functions and data management capabilities.

Technical Specifications and Configurations

The BEP floor scale is available in several sizes and material finishes to meet the most diverse industrial requirements.

Capacity and Dimensions

A platformok kapacitása 300 kg -tól egészen 3000 kg -ig terjed, a méretek pedig 800 x 800 mm -től egészen 2000 x 1500 mm-ig választhatók.

Dimensions (mm)	Capacity (kg)	Resolution (g)	Painted Version	AISI 304 Stainless Steel Version
800 x 800	300	100	•	•
800 x 800	600	200	•	•
1000 x 1000	300	100	•	•
1000 x 1000	600	200	•	•
1250 x 1000	600	200	•	•
1250 x 1000	1500	500	•	•
1250 x 1000	3000	1000	•	•
1250 x 1250	600	200	•	•
1250 x 1250	1500	500	•	•
1250 x 1250	3000	1000	•	•
1500 x 1250	600	200	•	•
1500 x 1250	1500	500	•	•
1500 x 1250	3000	1000	•	•
1500 x 1500	1500	500	•	•
1500 x 1500	3000	1000	•	•
2000 x 1500	1500	500	•	•
2000 x 1500	3000	1000	•	•

Note: In the table, the „•” symbol indicates the available version for the given size and capacity.

Material Choice

The BEP platforms are available in two main versions, corresponding to different environmental requirements:

1. Painted Configuration: Ideal for general industrial applications where durability and cost-effectiveness are the main considerations.
2. AISI 304 Stainless Steel Version: An excellent choice for food processing, chemical, or wet environments where a high level of hygiene and corrosion resistance is required.

Indicator Compatibility and Functionality

For achieving optimal performance of the BEP platforms, the following multifunction indicators are recommended:

• GI400 Series: Provides basic and reliable weighing functions.
• GI410 Series: Offers advanced functions such as piece counting, weight check (limit functions), and advanced data processing capabilities.

These indicators enable users to adapt measurements to specific workflows, whether for simple weighing or complex process control.

Application Areas

Due to the versatility of the BEP series floor scales, they are ideal for the following areas:

• Logistics and Warehousing: Fast and accurate weighing of large pallets and shipments.
• Production lines: Weight checking of components or finished products as part of quality assurance.
• Raw material processing: Nagy mennyiségű alapanyagok (pl.: granulátumok, porok) adagolásának és mérésének ellenőrzése.
• Trade: Settlement based on the weight of larger batches.

The BEP floor scale is the perfect fusion of reliability, precision, and ergonomic design, significantly optimizing measurement processes even in the most demanding industrial environments.
