TP XBAT Weighing Pallet Truck – Designed for Intensive Use
The TP XBAT is a fork technology, high-capacity pallet stacker forklift, developed specifically to meet the demands of intensive industrial environments. This equipment not only guarantees the safe transport of loads but also significantly optimizes material handling processes, minimizing weighing time and increasing workflow efficiency.
The TP XBAT combines reliability and durability with modern weighing technology, ensuring precise data acquisition and integration with existing enterprise resource planning (ERP) systems.
Key Features and Advantages
High Performance, Interchangeable Battery System
One of the key components of the TP XBAT is its removable and rechargeable battery, which ensures continuous operation even across multiple shifts:
- Battery Type: 12V / 5Ah
- Operating Time (Autonomy): Up to 40 hours on a single charge. This long operating time guarantees that the truck can perform tasks throughout the day without interruption, reducing downtime.
Excellent Durability and Construction
The truck's construction is resistant to harsh conditions and is available in various designs for optimal adaptation:
- Optional Construction Materials: Stainless steel (INOX) and Painted steel.
- Wheels: They have a polyurethane outer coating for excellent grip and floor surface protection.
- Maximum Lifting Height: 19 cm.
Intelligens Mérlegelési Funkciók
The built-in weighing system allows for immediate and precise measurement of loads during transport. With the help of GISCALE software, measurement data can be easily transferred and integrated into the user's various software solutions.
Main Functions and Operating Modes
The TP XBAT weighing pallet truck features several advanced functions that increase the accuracy of logistics and production processes:
- Darabszámlálás:
- Enables automatic determination of the number of items on the platform based on the programmed average unit weight (PMU). This is critically important for inventory management and during order picking.
- Ellenőrző Mérleg:
- A GI410i súlykijelző beépített ellenőrző mérleg funkcióval rendelkezik, amely Megfelelő/Nem megfelelő módot kínál. Ez biztosítja, hogy a szállítmányok megfeleljenek a meghatározott súlytoleranciáknak.
- Commercial Documentation and Storage:
- Tare Memory: For detailed listing of stored weights, capable of storing up to 400 items.
- Totalizer: Allows for the summation of accumulated weights in memory, and displays the total number of weighings.
- Legal Metrology Suitability:
- Certain models are valid for legal metrology purposes, which is essential for commercial transactions and compliance with regulatory requirements.
Technical Specifications and Configurations
The TP XBAT scale family ranges widely in terms of load capacity and accuracy, tailored to different user requirements.
| Capacity (kg) |
Design |
Resolution (g) |
Printer |
Legal Metrology |
| 1000 – 2000 |
Painted |
200 – 500 |
No |
No |
| 1000 – 2000 |
Painted |
500 – 1000 |
No |
No |
| 1000 – 2000 |
Painted |
200 – 500 |
Yes (M) |
Yes |
| 1000 – 2000 |
Painted |
500 – 1000 |
Yes (M) |
Yes |
| 1000 – 2000 |
INOX |
200 – 500 |
No |
No |
| 1000 – 2000 |
INOX |
500 – 1000 |
No |
No |
| 1000 – 2000 |
INOX |
200 – 500 |
Yes (M) |
Yes |
| 1000 – 2000 |
INOX |
500 – 1000 |
Yes (M) |
Yes |
Note: The IP protection level may vary depending on the presence of the printer.
Optional Accessories and Customization
The flexibility of the system is further enhanced by selectable accessories, allowing the scale to be adapted to specific environments and data management requirements:
- Pót akkumulátor Csomag: Additional batteries ensure uninterrupted 24/7 operation.
- WIFI Communication Card: Ensures wireless data transfer across the network.
- Additional Memory Card (ALIBI/DSD): Necessary for connecting metrologically certified (M) scale models to the software and ensuring secure data logging.
- Separate Battery for ATEX Zones: External batteries developed specifically for explosive risk environments (ATEX Zones 2/22) are available.
Accessory Models
The TP XBAT family also includes other models that cater to special requirements:
- TP410i: Stainless steel weighing scale with digital LCD display, valid for legal metrology.
- TP410i ATEX: ATEX certified weighing scale in stainless steel version with digital LCD display, valid for legal metrology.
The TP XBAT forklift is the ideal choice for any business where heavy-duty material handling must be paired with precise, documentable measurement, thereby maximizing efficiency and minimizing the possibility of errors.
