The Consul 2-post lift Premium EL® 2.35 MB model represents the highest level of professionalism in workshop equipment. This exceptionally high-quality, base frame free two-post lift has been designed according to Mercedes-Benz specifications, offering an ideal solution for lifting smaller vehicles (e.g., Smart Fortwo BR453) and long-wheelbase medium-sized vans (e.g., VW T6). The engineering precision and robust design of the Consul guarantee safe and efficient work performance.
This lift has been designed focusing on durability, precise operation, and user-friendly handling.
Construction Elements:
Special Extruded Profile Columns: The columns are made from a special extruded profile, which ensures maximum rigidity and stability even under the most intensive use.
Installation Orientation: The columns are installed perpendicular to the vehicle's approach direction, optimizing the working area.
Carriage Guide: The load-bearing carriages are guided by six (6) rollers, ensuring smooth and precise movement during lifting and lowering.
Loading System: A combination of a bronze loading nut and a cast alloy safety nut guarantees long service life and reliable support.
Lubrication Dispenser: Built-in oil distribution system for lubricating the support elements, minimizing maintenance requirements.
Safety Features:
Broken nut raise lock-down features.
Acoustic (audible) foot protection for safe working.
Control: Softline push-button control with a computer-controlled leveling system for millimeter-precise positioning.
Main Switch: Lockable main switch located directly on the column for easy access and complete power disconnection.
Additional Convenience:
Padded door bumper.
Adjustable pick-up plate (approx. 30 mm), providing flexibility for different chassis heights.
Full cladding of the inner parts of the column to enhance protection and aesthetics.
Automatic Arm Locking: Automatic arm locking mechanism, locking at 300 mm.
Standards and Protection:
Protection Class: IP 54.
Certifications: GS approval, DIN EN 1493, CE approval.
Delivery Accessories and Color:
Color: The lift is supplied in RAL 7015 color.
Accessories:
Document holder (accessory).
2 pcs tool trays (accessory).
Special adapter for prism pick-up (for GW vehicles, with and without footrest).
50 mm spacers (accessory).
Infill materials (accessory).
Important Note: The specified maximum lifting heights can be achieved by using optional accessories. The lowest pick-up heights are achieved under optimal floor conditions.
For maximum flexibility, the lift can be expanded with several options:
Self-supporting Base Frame: Optionally available accessory base frame.
Second Control Unit: It is also possible to install a second control unit.
Second Control Box for Service Column: Second control box for the service column, specifically designed for Consul 2.35 – 2.45 Premium models.
Drive-on Ramps: 1 set = 4 ramps.
Pick-up Supports with Rotating Plates: 4 pieces, Ø 100 mm plates (instead of the standard Ø 130 mm).
Fixing Materials: Mounting set for all Consul 2 two-post lifts up to 3,500 kg capacity (12 M12 anchor bolts, threaded rods, and plates).
Diagnostic Software: Consul ConSoft diagnostic software for 2-post lifts.
Limit Switch with Light Barrier: Ceiling limit switch with light barrier.
Manual Limit Switch: Manually operated ceiling limit switch.
The table below details the critical technical parameters of the Consul 2 two-post lift Premium EL® 2.35 MB model:
| Parameter | Value | Note |
|---|---|---|
| Rated load capacity | 3,500 kg | |
| Lifting height | ca. 2.005* mm | Available with optional accessories |
| Lifting/Lowering Time | approx. 35 seconds | |
| Lowest Free Height | ca. 95** mm | Under optimal floor conditions |
| Long arm extension range | approx. 650 – 1,340 mm | 3-part design |
| Set-up width | approx. 3.400 mm | |
| Installation Height | ca. 2.560 mm | |
| Distance between columns | approx. 2.830 mm | |
| Drive-through width | ca. 2.390 mm | |
| Power supply | 400 V / 50 Hz | Three-phase |
| Drive Power | 2 x 3.0 kW | |
| Fuse Protection | 20 A slow-blow |
Further Information:
Detailed technical documentation is available for the product in PDF format:
Brochure DE: Detailed German brochure.
Brochure EN: Detailed English brochure.
Installation Plan: Precise dimension drawings for installation.
This Consul Premium EL® 2.35 MB lift is the ideal choice for workshops seeking a reliable, high-performance, and flexible lifting solution to service modern vehicle fleets, all in compliance with the strictest safety and quality regulations.
