The J.A. Becker & Söhne V 190/300 NG3 model is a plug-in technology, four-stage natural gas booster compressor specifically designed for high-performance and reliable gas compression tasks. This equipment provides an ideal solution for industrial applications where the inlet pressure is low, but the outlet pressure must reach 300 bar. The V 190/300 NG3 reflects J.A. Becker & Söhne's commitment to quality, efficiency, and longevity, avoiding „mass-produced solutions” (NO 08/15 PRODUCTS).
This compressor provides excellent performance and reliability through the following key features:
Excellent Efficient Cooling: The unit's advanced cooling system ensures optimal operating temperature, minimizing energy loss and increasing system lifespan. Temperature control is critically important in gas compression processes, especially for high-pressure applications.
Fully Automatic Discharge: The fully automated depressurization function simplifies operation and maintenance, ensuring safe shutdown and rapid reduction of operating pressure when necessary.
Long Maintenance Cycles: As a result of its robust construction and excellent quality components, the V 190/300 NG3 features long maintenance intervals, significantly reducing downtime and operating costs.
High Performance: The flow rate range between 115.8 and 186.0 m³/h (depending on inlet pressure) ensures flexible applicability to meet various gas supply requirements.
The V 190/300 NG3 compressor offers precise engineering solutions detailed in the following table:
| Parameter | Value | Note |
|---|---|---|
| Model | V 190/300 NG3 | Four-stage Natural Gas Booster Compressor |
| Maximum Operating Pressure | 300 bar | For high-pressure applications |
| Number of Stages / Cylinders | 4 / 4 | Four compression stages |
| Electric Motor Power | 40 kW | Drive Unit |
| Rotational speed | 1.500 U/min | |
| Inlet Pressure (Range) | 1.5 / 3 / 3.5 bar | Optimized for multiple inlet pressures |
| Flow Rate (Range) | 1,930 / 2,715 / 3,100 l/min | Depending on the inlet pressure |
Note on Flow Rate: The specified flow rate values (1,930 l/min, 2,715 l/min, 3,100 l/min) correspond to different inlet pressures (1.5 bar, 3 bar, 3.5 bar), demonstrating the compressor's flexibility in adapting to gas supply conditions.
The V 190/300 NG3 compressor is a first-class product in every respect, an ideal choice for natural gas (NG – Natural Gas) after-compression, where the existing network pressure needs to be significantly increased for further transport or storage purposes.
Equipment manufactured by J.A. Becker & Söhne is known for its reliability and compliance with strict quality requirements. In the case of the V 190/300 NG3, this quality manifests in the following areas:
Robust Construction: The compressor housing and internal components withstand continuous, high loads, which is essential for reaching 300 bar pressure.
Cooling System Optimization: Significant heat is generated during gas compression. Efficient cooling not only increases safety but also prevents degradation of gas quality and premature wear of mechanical parts.
Automation and Supervision: The fully automatic blow-off function is integrated into the control system, ensuring the compressor always operates under optimal conditions and shuts down safely in case of need.
This model is an integral part of the J.A. Becker & Söhne lifting technology and compressor portfolio, meeting the highest industrial standards. Detailed technical datasheets and brochures are available for further information and to review installation requirements.
The V 190/300 NG3 compressor is the result of precision engineering work, guaranteeing stable and efficient natural gas after-compression even in the most demanding industrial environments.
