The J.A. Becker & Söhne SV 1101/80 He helium compressor is a state-of-the-art, three-stage system specifically designed for high-performance gas compression tasks. This model is ideally suited for industrial applications requiring reliable, high-pressure helium supply, reaching a maximum operating pressure of 80 bar. The unit reflects J.A. Becker & Söhne's commitment to quality, efficiency, and longevity, avoiding „off-the-shelf solutions” (NO 08/15 PRODUCTS).
The SV 1101/80 He compressor features several outstanding characteristics that ensure continuous and efficient operation:
High-Efficiency Cooling: The advanced cooling system guarantees optimal operating temperatures, which is crucial during helium compression, thereby increasing system stability and lifespan.
Fully Automatic Discharge: The fully automated purge function minimizes the need for human intervention, ensuring smooth and safe operation between cycles.
Long Maintenance Intervals: As a result of the robust design and superior quality components, maintenance requirements are significantly reduced, maximizing uptime and lowering operating costs.
First-Class Product in Every Aspect: The design and construction of the unit comply with the highest industrial standards, ensuring reliability even in the most demanding environments.
The precise and detailed technical specifications for the SV 1101/80 He compressor are summarized in the table below:
| Parameter | Value | Unit of Measure | Note |
|---|---|---|---|
| Volume Flow (Volume Flow) | 1.100 | l/min | Equivalent to 66.0 m³/h |
| Maximum Operating Pressure | 80 | bar | For high-pressure applications |
| Compression Stages / Cylinder | 3 / 3 | – | Three-stage compression |
| Electric Motor Power | 18,5 | kW | Powerful Drive |
| Speed (Speed) | 1.500 | rpm | Optimized operating speed |
The 3-stage design allows for efficient and controlled compression of helium up to the desired final pressure of 80 bar. The flow rate of 1100 liters/minute (or 66.0 m³/hour) ensures the system can handle large volumes of gas. The 18.5 kW electric motor operates at a speed of 1500 revolutions/minute, creating an ideal balance between performance, efficiency, and mechanical stress.
Although the text does not detail all application areas, helium compressors typically play a critical role in the following sectors:
Scientific Research & Development: Maintenance of high-pressure helium systems for experimental purposes.
Industrial Gas Supply: Production of special gas mixtures or filling of high-pressure storage systems.
Welding Technology and Laser Technology: Supply of high-purity helium for special welding processes or as a cooling/shielding gas for industrial lasers.
Further detailed information is available to users in a downloadable format, which assists with installation, operation, and a deeper understanding of the system:
Datasheet Download: Detailed technical specifications and drawings.
Brochure Download: Comprehensive product overview presenting the compressor family.
The SV 1101/80 He model is a symbol of J.A. Becker & Söhne's engineering precision, guaranteeing long-term, trouble-free operation even under the highest pressure requirements.
