This detailed product description refers to the pressure reducer manufactured by Wieländer+Schill, which has a fixed operating pressure of 2 bar and is specially designed for gas torches. This component is essential for ensuring precise and safe gas supply during automotive body repair and metalworking tasks.
The pressure reducer with part number 808022 is a reliable solution for guaranteeing the optimal operation of gas-powered equipment, especially gas torches. The device ensures a fixed operating pressure of 2 bar, which is critical for a stable flame pattern and efficient work performance. The maximum flow rate is 6 kg/h, providing sufficient capacity for most professional applications.
The reducer is made of high-quality materials, ensuring long service life and reliable operation even in demanding workshop environments. The combination of brass, copper, and plastic (kunststoff) guarantees corrosion resistance and mechanical stability.
The table below summarizes the most important technical parameters of the pressure reducer:
| Property | Value | Note |
|---|---|---|
| Part number | 808022 | Unique Identifier |
| Operating pressure | 2 bar | Fixed, preset value |
| Maximum flow rate | 6 kg/h | Gas Flow Capacity |
| Connection (Hose) | R3/8″ li | Internal Thread Connection |
| Material composition | Brass, Copper, Plastic (kunststoff) | Durable and resistant structure |
| Dimensions (L x W x H) | 73.7 x 63 x 35.9 mm | Compact design |
| Weight | 0.250 kg | Light weight for easy handling |
Fixed Operating Pressure (2 bar):
The main advantage of this device is the fixed, non-adjustable 2 bar pressure. This setting is ideal for the gas torches recommended by Wieländer+Schill, as it eliminates user errors and guarantees continuously optimal combustion conditions. Stable pressure is essential for precise soldering and tinning work, where temperature control is crucial.
Flow Capacity (6 kg/h):
The maximum flow rate of 6 kg/h ensures that the reducer can supply enough gas for fast and efficient work without causing a pressure drop under load.
Connection Accuracy:
A R3/8″ li (female thread) hose connection of standard size, ensuring a reliable and leak-free connection to the appropriate gas hose. The precise thread length and design minimize installation difficulties.
Material Usage and Durability:
The use of brass and copper at critical points provides excellent resistance against corrosion and the effects of gases. Plastic elements contribute to weight reduction and insulation. This robust construction guarantees that the reducer meets strict workshop requirements over the long term.
This pressure reducer can primarily be used in the following areas:
Body Panel Repair: Ideal for tinning processes, where precise heat input is essential for preparing and repairing metal surfaces.
Gas Burner Operation: For any gas torch that requires an operating pressure of 2 bar.
Metal Industry Operations: General metal welding, soldering, or heating tasks where controlling gas pressure is critical.
A complementary pressure reducer related to this product is available, featuring a different cylinder connection but identical performance data:
Pressure Reducer | DIN-Combi × R3/8″ li (Part Number: 808023)
This model features the following difference:
Cylinder connection: DIN-combi
Hose connection: R3/8″ li
Operating pressure: 2 bar (fixed)
Maximum flow rate: 6 kg/h
This accessory option allows users to adapt the regulator to their existing gas cylinder connection type while retaining the precise pressure regulation provided by model 808022.
Wieländer+Schill is committed to the highest quality standards. The company holds ISO 9001 (Quality Management System) and ISO 14001 (Environmental Management System) certifications, guaranteeing that manufacturing processes and products meet international expectations. This pressure regulator is also brought to market as part of this rigorous quality assurance framework.
This pressure regulator belongs to the Wieländer+Schill „Dent Removal Technology & Metalworking” category, reinforcing the brand's position in the market for professional body repair tools.
