This detailed description refers to the Consul 0.40 S BA type, floor-recessed, electrohydraulic scissor lift, which is perfectly suited for workshop and service environments, especially for lifting vehicles up to 4,000 kg capacity. Thanks to the 4560 mm track length, it is ideal for servicing passenger cars and light commercial vehicles, including wheel alignment tasks (with optional accessories).
The Consul 0.40 S BA model combines reliability, safety, and ease of handling, ensuring efficient work execution in the workshop.
Design Features:
Floor-Installation Design (BA): This configuration allows the lift to sink completely to floor level, so vehicles can easily drive onto it without the need for external ramps or a sunken structure (installation height is only approx. 260 mm).
Platform Material: The tracks are made of special rolled profile steel, which guarantees high stability and a long service life.
Hydraulic System: The application of electrohydraulic control ensures a precise and reliable lifting/lowering process. The Master/Slave hydraulic system enables balanced operation.
Pneumatic Lowering Release: During lowering, the locking mechanism can be released pneumatically with a push button, resulting in faster and more convenient operation.
Mechanical Locking Device: Mechanical locking system provides safe support for the vehicle at the desired height in 17 positions.
Acoustic Protection Elements: Foot protection ensures personal safety in the operating zone.
Bearing: Split, 20 mm thick fixed and sliding bearings (hot-dip galvanized as standard) ensure smooth movement and wear resistance of the tracks.
Wheel Alignment Readiness: The lift is calibrated for wheel alignment. Optionally available are split, 20 mm thick bearings.
Integrated Accessories: The platforms feature a built-in rail for positioning the hydraulic jacking beams, as well as drive-on ramps and a rollback stop.
Protection: Features IP 54 protection rating, a 230 V socket, GS certificate, and compliance with DIN EN 1493 and CE.
The table below summarizes the critical technical parameters of the Consul 0.40 S BA (4560 mm) scissor lift:
| Parameter | Value | Note |
|---|---|---|
| Item Number (SKU) | 732420 | |
| Manufacturer Number (HAN) | 473662 | |
| Category | Scissor Lifts | |
| Rated load capacity | 4.200 kg | |
| Lifting height | ca. 2.100 mm | |
| Lifting Time (loaded) | approx. 35 seconds | |
| Set-up width | ca. 2.240 mm | |
| Installation length | ca. 5.670 mm | |
| Drive-up height | ca. 260 mm | Floor-recessed version |
| Power supply | 400 V / 50 Hz | Three-phase mains |
| Drive Power | 5.5 kW | |
| Fuse Protection | 20 A slow-blow | |
| Width of runways | ca. 650 mm | |
| Length of runways | ca. 4.560 mm |
The Consul 0.40 S BA lift can be flexibly expanded with accessories tailored to workshop needs (these are ordered separately):
Anti-slip Coating (Not retrofittable): Applicable to the surface of the platforms, increases grip.
Approach/Departure Ramps (with Roll-back Protection): For safe vehicle approach. The standard kit includes ramps approximately 1,000 mm long (1 set = 2 pcs).
Straight, Extended Ramp: Longer ramps, approx. 1,500 mm, are available (1 set = 2 pcs).
Control Box Location on the Right Side (Surcharge): Customization of the control unit position.
Fixing Kit (for 0.35/0.40 series): Contains 28 pcs of M16 anchor bolts and nuts for secure fixing.
Lighting (Surcharge for Factory Installation): Optional lighting solutions, such as 4 LED lamps (1,235 mm long, at 45° angle) with switch and cabling.
Hot-dip Galvanizing of Platforms: High-quality hot-dip galvanizing of the surface and sides, especially recommended for AV/AM versions.
Platform Extension (250 mm, max. 1 pc): Further increase in the length of the runways.
Hydraulic Wheel Alignment Tester Kit (630): 18 movement direction tester (longitudinal/transversal), for max. 2,000 kg vehicles. Can be built into the platform with a 50 mm structure, includes approach block (for lifts without wheel alignment kit).
This Consul scissor lift is the ideal choice for workshops looking for a reliable, high-capacity, floor-mounted lifting equipment that complies with strict European safety regulations.
