This detailed product description presents the highly precise C15 type Closing Die, which belongs to the Wieländer+Schill XSeries professional riveting technology, specifically designed for the professional and durable fastening of Self Piercing Rivets (SPR). This component is essential during body repair work, ensuring factory-quality joints.
The C15 Closing Die is a crucial element of Wieländer+Schill's professional riveting systems. It serves specifically to form the closing (lower) side of Self-Piercing Rivets (SPR), guaranteeing the optimal formation of the rivet head and a firm, reliable connection between body panels. The die is designed to withstand high mechanical stress and continuous use, making it an ideal choice for high-traffic workshops and service centers.
The product is compatible with Ford specifications, which is particularly important during repairs compliant with OEM (Original Equipment Manufacturer) recommendations.
Precise Design: The extremely precise geometry of the die ensures that the closing side of the SPR rivet perfectly matches the upper rivet head, thus achieving maximum joint strength and durability.
Durability: Made from high-quality materials that resist high pressure and wear, guaranteeing a long service life for the die.
Ford Compatibility: The die specifically meets Ford identifiers (Ford ID – DG1002220 HR1R1,5), which is essential for adhering to the repair procedures prescribed by the brand.
XSeries System Integration: Fully integrable into the Wieländer+Schill XSeries professional riveting technology, ensuring seamless and efficient operation.
Easy Replacement: Designed for quick and easy replacement on compatible riveting machines.
The basic dimensions and identifiers of the C15 Closing Die are as follows:
| Property | Value | Note |
|---|---|---|
| Item number | 700540 | The unique identifier of the product. |
| Product Name | C15 Closing Die for Self-Piercing Rivets (SPR) | |
| Field of application | Self-Piercing Rivets (SPR) | |
| Ford Identifier | DG1002220 HR1R1,5 | Identifier compliant with factory specifications. |
| Length | 18 mm | |
| Width (Width) | 18 mm | |
| Height | 27 mm | |
| Category | XSeries – Professional Riveting Technology | |
| Sub-category | Dies | Punches |
The C15 Closing Die exerts its effect at the critical point of the riveting process, on the lower surface of the rivet. During SPR riveting, the rivet pierces the upper material layer, and then under the action of the die (in this case, the C15), the lower end of the rivet deforms radially or axially, creating the solid closing head.
The die's dimensions of 18x18x27 mm ensure compatibility with standard die holders and appropriate force application for rivet deformation without damaging the surrounding material. Dies manufactured within precise tolerance ranges are essential for repairing modern high-strength steel bodies, where joint quality directly affects the structural integrity of the vehicle.
This die is part of the wide range of Wieländer+Schill products, representing the forefront of body repair technologies, including welding technology, separation tools, and dent removal systems. As part of quality assurance, the company holds ISO 9001 and ISO 14001 certifications, which guarantee product reliability and consideration of environmental aspects during manufacturing.
The C15 Closing Die is the ideal choice for any technician seeking to comply with the highest standards of body repair, especially when repairing Ford brand vehicles.
