B5CL Type Floor Scale System – High Capacity Industrial Solution
A B5CL típusú padlómérleg platform egy robusztus, nagy teherbírású mérési megoldás, amelyet kifejezetten a legigényesebb ipari környezetekhez terveztek. Ez a rendszer a kiváló mechanikai stabilitást ötvözi a precíz méréssel, ideális megoldást nyújtva raktárakban, gyártósorokon és logisztikai központokban történő anyagmozgatás és készletellenőrzés során.
A B5CL platformot négy nagy teherbírású mérőcella alkotja, amelyek dupla keretes szerkezettel rendelkeznek a maximális merevség és a terhelés egyenletes elosztása érdekében. A mechanikai kialakítás kulcsfontosságú eleme a
gömb- és foglalat csuklós rendszer, complemented by spheres, which ensures perfect horizontal leveling of the platform and compensates for distortions caused by uneven floor surfaces, guaranteeing accurate measurement even under extreme load conditions.
The weighing system can be flexibly integrated with the
GI400 or GI410 series multifunctional indicators, which provide the user with a wide range of data processing and communication capabilities.
Key Features and Advantages
- Outstanding Mechanical Stability: The double-frame structure and four-point suspension guarantee long-term reliability and high accuracy.
- Kompenzációs Rendszer: The ball-and-socket joint design minimizes measurement errors resulting from wind load, uneven load distribution, or floor irregularities.
- Wide Capacity Range: A platformok 600 kg -tól egészen 6000 kg -ig terjedő kapacitással érhetők el, rugalmasan alkalmazkodva a különböző ipari igényekhez.
- Material Selection: Available in two main versions: durable painted steel and hygienic, easy-to-clean AISI 304 stainless steel.
Technical Specifications and Selectable Configurations
The dimensions and capacities of the B5CL floor scales can be adapted to the application area. The table below details the available dimensions, maximum load capacity, and the corresponding reading accuracy (resolution).
| Dimensions (mm) |
Capacity (kg) |
Reading (g) |
Painted Version |
Stainless Steel AISI 304 |
| 1250 x 1250 |
600 |
200 |
• |
• |
| 1250 x 1250 |
1500 |
500 |
• |
• |
| 1250 x 1250 |
3000 |
1000 |
• |
• |
| 1500 x 1250 |
600 |
200 |
• |
• |
| 1500 x 1250 |
1500 |
500 |
• |
• |
| 1500 x 1250 |
3000 |
1000 |
• |
• |
| 1500 x 1500 |
1500 |
500 |
• |
• |
| 1500 x 1500 |
3000 |
1000 |
• |
• |
| 1500 x 1500 |
6000 |
2000 |
• |
• |
| 2000 x 1500 |
1500 |
500 |
• |
• |
| 2000 x 1500 |
3000 |
1000 |
• |
• |
| 2000 x 1500 |
6000 |
2000 |
• |
|
| 2000 x 2000 |
6000 |
2000 |
• |
|
| 2500 x 1500 |
1500 |
500 |
• |
|
| 2500 x 1500 |
3000 |
1000 |
• |
|
Note: The ‘•’ symbol in the table indicates the availability of the given size/capacity combination in the appropriate material grade.
Application Areas
The B5CL platforms are ideal for areas where the precise weighing of large-sized or bulky items is required:
- Logistics & Transport: Checking the weight of containers, pallets, and large packages to optimize shipping costs.
- Manufacturing and Assembly: Alkatrészek vagy félkész termékek súly szerinti adagolása, minőség-ellenőrzés.
- Wholesale: Nagy mennyiségű alapanyag (pl.: vegyi anyagok, fémek, építőanyagok) mérése.
- Food Industry: The AISI 304 stainless steel version is exceptionally suitable for hygienically sensitive environments.
Compatible Weighing Units
The performance of the B5CL platforms is ensured by compatible indicators. The
GI400 and GI410 series indicators offer professional functions, such as:
- Support for multiple units of measurement.
- Zeroing, gross/net weighing functions.
- Data storage and printing capabilities (with external printer).
- RS232 or other communication interfaces (depending on the display type) for integration into process control systems.
The B5CL system is the perfect synergy of reliability, high load capacity, and precise mechanical design, ensuring efficient and accurate measurement in industrial processes over the long term.
