The Rotrix TSH-008 is a professional, desktop test stand specifically developed for the comprehensive assessment of the technical condition of vehicle starting and charging systems, as well as voltage regulator units. This versatile device is an ideal choice for service centers and workshops where fast and accurate diagnostics of alternators, starter motors, and regulators equipped with 12V, 24V, and even 48V systems are essential.
The TSH-008 is not just a simple tester; its advanced features, such as oscilloscope-style display and automated testing capabilities, significantly speed up troubleshooting and increase workflow efficiency.
The Rotrix TSH-008 test bench is characterized by a combination of user-friendly design and high-level technical capabilities:
Graphical Parameter Display: The display of measured parameters occurs in the form of oscilloscope graphs, which visually aids in the precise identification of faults.
Semi-Automatic Generator Test: Generator testing can be performed in manual or semi-automatic mode. The results of the semi-automatic test can be saved and printed, ensuring documentation.
Integrated Databases: Built-in databases assist in the quick identification and loading of test profiles for both generators and voltage regulators.
Convenient Clamping: The clamping system for the units under test provides simple and quick access to the components.
Automatic Belt Tensioning: The belt tension required for driving the generator is automatically set by the stand, eliminating inaccuracies arising from manual adjustment.
Modern User Interface: A 7-inch touchscreen ensures easy navigation and quick setups.
Compact Design: Its desktop design provides a space-saving solution in workshop environments.
Free Software Updates: The device features automatic software updates, ensuring continuous compatibility with the latest vehicle technologies.
Special Diagnostic Cables: Optionally available special cables for connection to modern generators featuring complex connectors.
The TSH-008 test bench is used to assess the technical condition of the following main units:
Generators (12V/24V/48V): Testing generators with different connectors and control protocols under load.
Voltage Regulators: Independent of the generators, standalone testing under load.
Starter Motors (12V/24V): Basic testing of starter motors for passenger cars and heavy-duty commercial vehicles.
| Parameter | Value |
|---|---|
| Dimensions (L×W×H) | 770 × 640 × 500 mm |
| Weight | 85 kg |
| Supply Voltage | 400 V |
| Drive Power | 4 kw |
| Number of Batteries | Two identical 12V batteries |
| Automatic battery charging | Yes |
| Rated voltage of the tested unit | 12V, 24V (48V) |
During generator testing, the load and drive speed are continuously adjustable, enabling the simulation of real operating conditions.
| Parameter | 12V Mode | 24V Mode | 48V Mode |
|---|---|---|---|
| Load | 150 A | 100 A | 50 A |
| Load Setting | Continuous (0-100%) | Continuous (0-100%) | Continuous (0-100%) |
| Drive Speed | 0–3000 rpm | 0–3000 rpm | 0–3000 rpm |
| Drive Speed Setting | Stepless | Stepless | Stepless |
| Drive type | Belt (V-belt or Poly-V) | Belt (V-belt or Poly-V) | Belt (V-belt or Poly-V) |
Testable Alternator Types:
12V Systems: Lamp, SIG, RLO, RVC, C KOREA, P-D, C JAPAN, COM (LIN, BSS)
24V Systems: Lamp, COM (LIN)
The display shows numerous measured parameters in the form of graphs, diagrams, and numerical values.
The regulators are tested under simulated engine speed and load conditions.
| Parameter | Value |
|---|---|
| Engine Speed Simulation | 0 – 6000 rpm |
| Load Simulation | 0 – 100% |
Tested Voltage Regulator Parameters:
Stabilization voltage
Current through the rotor winding
Control lamp (D+)
COM Voltage Regulators (Others):
ID
Voltage regulator type
Baud Rate
Protocol type
Error Codes
Testable Voltage Regulator Types:
12V Systems: Lamp, SIG, RLO, RVC, C KOREA, P-D, C JAPAN, COM (LIN, BSS)
24V Systems: Lamp, COM (LIN)
During the starter motor test, the system measures the starting characteristics and the voltage drop between terminals K30 and K45.
Software update: Free automatic software update in the first year.
Results Management: Saving and printing test results is supported.
Network Connection: Wi-Fi (802.11 a/b/g/ac) connectivity option.
External Connectors: 2 pieces of USB 2.0 port for connecting external devices.
The Rotrix TSH-008 3-in-1 tester is the ideal solution for reliable and efficient maintenance of modern vehicle electrical systems.
