The PIUSI VISCOMAT VANE series is an excellent performance, reliable electric pumping system specifically designed for pumping diesel, oil, as well as HVO and XTL fuels. This robust unit provides an ideal solution for industrial environments where high suction capacity is required for the transfer of high-viscosity fluids. VISCOMAT VANE pumps deliver efficient and constant flow rates for the most demanding applications, such as in mining, construction, and agriculture.
The VISCOMAT VANE pumps are available in two main versions: VISCOMAT VANE 70 and VISCOMAT VANE 90. These AC (alternating current) versions are ideally suited for situations where the reliable and continuous pumping of medium-high viscosity fluids (up to 500 cSt) is the goal.
In designing the VISCOMAT VANE pumps, PIUSI prioritized high performance and long-term reliability, especially considering the challenges posed by oil density.
The higher density of oils requires greater performance during pumping. The VISCOMAT VANE system is composed of a self-priming AC vane pump which guarantees constant flow rate and regularity even with more viscous media.
Capacity: Achieving flow rates up to 50 liters/minute.
Viscosity Handling: Capable of handling viscosity up to 500 cSt.
Continuous Operation: Continuous operation ensures high suction capacity.
Pressure: Maintaining pressure up to 6 bar.
The pumps are equipped with an asynchronous AC motor featuring enclosed and self-ventilated cooling. This design ensures optimal motor temperature and a long service life.
Motor Type: Asynchronous AC motor with enclosed and self-ventilated cooling.
Flexibility: Available in various voltage and frequency configurations (single- and three-phase), allowing adaptation to any working condition.
The internal components of the pump are optimized for durability, ensuring long-term, trouble-free operation of the system.
Rotor Material: Sintered steel rotor that ensures excellent strength during pumping.
Vanes: Resin-coated vanes that increase the rotor's resistance.
Maintainability: The shaft seal is accessible from the side of the pump, which facilitates maintenance and ensures protection against oil leakage.
The VISCOMAT VANE systems can be flexibly integrated into various systems and allow for fine-tuning of operation.
Adjustable By-pass: The by-pass valve integrated into the pump housing allows for control of operation even in case of a closed discharge line, preventing overpressure.
Application Areas: Ideal solution for mining, construction, industrial, and agricultural applications.
Portability: The design is mobile and ready for immediate use.
The specifications of the VISCOMAT VANE pumps ensure the optimal performance of the selected model for the task.
| Characteristic | VISCOMAT VANE 70 / 90 |
|---|---|
| Product Category | Fuel, Lubricant, Oil, Diesel/HVO/XTL |
| Application Area | Mining & Construction, Industrial, Agriculture |
| Pump Type | self-priming AC vane pump |
| Maximum Flow Rate | Up to 50 l/min |
| Maximum Horizontal Suction | High suction capacity |
| Maximum Pressure | 6 bar |
| Maximum Viscosity | 500 cSt |
| Motor | Asynchronous AC, closed, self-ventilating |
| Internal Components | Sintered steel rotor, resin vanes |
| Regulation | Integrated by-pass valve (for closed pipe) |
| Maintenance | Easily accessible shaft seal |
| Versions | VISCOMAT VANE 70 and VISCOMAT VANE 90 |
PIUSI offers several electrical configurations to meet global market demands. The table below presents some available models and their basic identifiers:
| Product code | Description |
|---|---|
| 000303000 | VISCOMAT 90 T 400V/50Hz |
| F00303M00 | VISCOMAT 90 M 230V – 50/60 |
| F0033190A | VISCOMAT 70 T 400/50 460/60 |
| F0033490A | VISCOMAT 70 230V 50/60Hz |
PIUSI VISCOMAT VANE pumps represent the „Made in PIUSI” quality, ensuring users the reliability and durability required for high-performance oil and fuel transfer. This versatile pump is an ideal choice for fluid management tasks in the toughest industrial environments.
