This product, the Triangular pulling tabs (Part number: 297013), an indispensable part of the Wieländer+Schill professional body repair tool set. Specifically designed to support fast and economical vehicle repair processes, especially in the area of dent removal.
These tabs Quick pulling hammer (Quick pulling hammer) can be used together, enabling the effective restoration of damaged body parts without the need for complex and time-consuming rework. The product belongs to the Welding technology category, and specifically to the Single-sided spot welding gun GT accessories as a weldable consumable.
The primary advantage of using triangular pulling tabs is the efficiency and cost-effectiveness. For bodywork specialists, this method offers a quick solution for removing small and medium-sized dents.
Fast and Economical Repair: It enables the quick pulling back of damaged surfaces, minimizing repair time and material consumption.
Reusability: After removing the welded tabs, if the tips are worn or damaged, they can be simply refiled (ground down), thus extending the service life of the component and reducing the frequency of consumable replacement.
Reliable Execution: The use of durable material and special coating ensures proper weldability and stability of the pulling process.
The precise design of the product guarantees compatibility with appropriate pulling systems.
| Property | Value | Note |
|---|---|---|
| Part number | 297013 | The unique identifier of the product |
| Packaging Unit (PU) | 15 pieces | Quantity per package |
| Material | Steel core | Strong, durable base material |
| Surface Treatment | Copper-plated | Ensures excellent weldability |
| Dimensions (Length x Width x Height) | 53 x 43 x 2 mm | Precise geometric data |
| Application | Dent pulling | Fast pulling technique |
| Compatibility | Quick pulling hammer | Essential tool for the pulling process |
The tabs with steel core which ensures the necessary mechanical strength to absorb the forces arising during the pulling operations. The critical surface with copper plating is provided. This coating is crucial during the spot welding process as it optimizes electrical conductivity and prevents excessive wear of the tools (e.g., welding gun electrodes) or adhesion to the workpiece.
The triangular shape with dimensions of 53 x 43 x 2 mm provides an ideal contact surface for various body curves, maximizing the number and stability of weld points on a given pulling area. The 2 mm thickness provides sufficient rigidity for transferring the pulling force.
These pulling tabs are part of modern body repair technologies where the goal is to restore the original condition of the body with minimal intervention.
Preparation: The damaged area must be cleaned of paint and contaminants.
Welding: The triangular tabs are welded to the damaged surface using the appropriate spot welding device (e.g., Single Sided Spot Welding Gun GT). The copper plating helps to create a clean, strong weld joint.
Pulling: Using the slide hammer, the dent is gently and gradually pulled out through the points fastened to the tabs.
Post-processing: After pulling, the tabs can be removed, and if necessary, the tips can be re-ground for the next use.
This system is the ideal choice for professionals who perform precise, spot-on interventions instead of traditional, large-scale pulling methods. The quality of Wieländer+Schill products guarantees long-term, reliable performance in the workshop environment.
