This detailed product description is for the WS Wieländer+Schill type HLW-13o pneumatic vehicle lift presents its technical features and advantages, specifically designed for professional bodywork and service tasks. This model offers an optimal solution for lifting heavier vehicles, ensuring comfortable and safe access to the vehicle's underbody and sills.
A key feature of the HLW platforms is that they lift the vehicle vertically, by gripping the wheels. This method enables stable lifting while also providing an ideal position for working on the wheel suspension and drivetrain. The lifting surfaces are equipped with grates to ensure adequate grip and drainage of contaminants.
During the design, great emphasis was placed on flexibility: the central part of the lift can be folded down, which allows work to be carried out on the body sills without the lift structure obstructing access.
Thanks to the 3.5-ton (3500 kg) load capacity, the HLW-13o model can handle heavier vehicles, including longer wheelbase models, thus increasing workshop flexibility.
Vertical Lifting at the Wheels: It lifts the vehicle by gripping the wheels, which guarantees a stable and safe position for working on the drivetrain and underbody.
Foldable Central Section: The foldable function of the central section is critically important for repairs and welding carried out on the sills, ensuring maximum accessibility.
Robust Design: The base frame, grates, and drive-over protection elements on every lift are galvanized, which ensures excellent corrosion protection and a long service life in the workshop environment.
Pneumatic Operation: Lifting is performed via a pneumatic system, which allows for reliable and fast operation.
High Load Capacity: 3500 kg maximum load capacity, making it suitable for lifting medium-sized commercial vehicles and heavier passenger cars.
The table below summarizes the most important technical parameters of the HLW-13o pneumatic lift:
| Parameter | Value | Note |
|---|---|---|
| Part number | 851052 | |
| Maximum Load Capacity | 3500 kg (3.5 t) | |
| Maximum Lifting Height | 1000 mm (100 cm) | |
| Operating Pressure | 5 bar | |
| Pneumatics (Max. Pressure) | P max. 8 bar | |
| Air Quality | According to ISO 8573-1 | |
| Length × Width × Height (Base Frame) | 3980 x 2100 x 114 mm | |
| Weight | 1050 kg | |
| Noise Level (Sound Pressure Level) | < 70 dB(A) | Low noise level in the working environment. |
| Material composition | Metal, Plastic, Rubber | |
| Conformity Declaration | According to 2006/42/EC | Complies with the EU Machinery Directive. |
For safe and stable operation, proper installation is essential.
ATTENTION! To prevent the movement of the lift, the base frame must be fastened (screwed) to the floor.
Steps for the fastening process:
The HLW-13o lift is the ideal choice for:
This pneumatic lift represents the quality and reliability of WS Wieländer+Schill, ensuring efficient and safe work even in the most demanding workshop environments.
