The Consul 2-Post In-ground Lift 2.35 MKS Optima is an excellent quality, professional vehicle lift, designed specifically to meet the needs of workshops and service centers. This two-cylinder, in-ground (Unterflur) lift offers an ideal solution for lifting passenger cars, with a maximum load capacity of 3,500 kg. The integrated cassette design and precise hydraulic system guarantee safe and efficient operation.
This lift belongs to the Consul C-Line and Z-Line product series and is categorized under Twin Ram Inground Lifts. The 2.35 MKS Optima model combines reliability and long service life with modern technical solutions.
Important note: This lifting unit exclusively with swivel-arm chassis configuration usable.
The Consul 2.35 MKS Optima lift includes several design elements that optimize usability and maintenance:
Integrated Cassette Design: The built-in cassette features a robust, hot-dip galvanized steel profile frame, which ensures excellent corrosion protection and stability during in-ground installation.
Chrome-plated Guide Pistons: The guide pistons of the hydraulic cylinders are hard-chromed, which minimizes friction, increases service life, and ensures smooth, precise lifting/lowering movement.
Electro-Hydraulic Drive: The power unit is located externally to the lifting unit, which facilitates access and servicing.
Mechanical Synchronization and Safety Device: The mechanical synchronization also functions as a safety device, ensuring perfect alignment of the two cylinders even under load.
Electronic Control with Stop Valve: The modern electronic control system allows for precise operation, and the built-in stop valve provides an extra layer of safety.
Cassette Ventilation and Network Connection: The cassette connection socket allows for connection to a DN 100 sized KG pipe network, which serves both for ventilating the cassette and for establishing the supply line network.
Hot-Dip Galvanized Cassette Cover: The cassette cover is completely hot-dip galvanized, making it resistant to moisture and chemical effects occurring in the workshop environment.
Certifications: The lift has an IP54 protection rating, GS certification, and complies with DIN EN 1493 and CE standards, guaranteeing adherence to the highest safety requirements.
The table below details the critical technical parameters of the Consul 2.35 MKS Optima lift:
| Parameter | Value | Note |
|---|---|---|
| Item Number (SKU) | 549584 | |
| Manufacturer Number (HAN) | 9656 | |
| Category | Twin Ram Inground Lifts | |
| Rated load capacity | 3,500 kg | For Passenger Cars |
| Lifting height | ca. 1.990 mm | |
| Lifting Time (loaded) | approx. 35 seconds | |
| Power supply | 400 V / 50 Hz | Three-phase mains |
| Drive Power | 3.3 kW | |
| Electrical Supply Voltage | 400 / 50 V / Hz | |
| Fuse Protection | 16 A slow-blow | |
| Oil quantity | approx. 10 liters | |
| Distance between columns | 1.380 mm | |
| Cylinder Diameter | ca. 130 mm | |
| Operating pressure | 150 bar |
Detailed documentation is available for the product for professional installation and operation:
Catalogue (Brochure): Detailed overview of the C-Line 2-Post In-ground Lift product family.
Foundation Plan: Precise instructions for the appropriate concreting and installation work (H224-33196.7 Consul 2.35 MK and MKS).
For maximum flexibility, Consul offers a range of accessories for this lift, allowing the workshop environment to be customized:
Consul Installation Cassette ex ante 1,380 mm: The installation cassette designed for the specific piston distance of 1,380 mm ensures precise and stable installation.
Consul Hydraulic Oil in a 5-liter can: HLP 22 quality hydraulic oil, suitable for all hydraulically driven Consul lifts. The required quantity depends on the type of lift.
Surcharge: Drive unit inside cassette: Optional item that allows the drive unit and wall control to be placed inside the cassette if external placement is not ideal.
Consul Installation Kit: May contain all necessary elements for professional installation.
Consul Control Unit according to OEM industrial standard: Special control unit that complies with OEM (original equipment manufacturer) industrial specifications. Specification of the OEM is required upon ordering.
Consul Recessed Lift Unit for Foreign Manufactured Cassettes: A lift unit compatible with foreign manufactured cassettes with a piston distance of 1,300 mm or 1,380 mm.
This Consul 2-Stempel Unterflur-Hebebühne 2.35 MKS Optima is the ideal choice for professionals seeking a reliable, high-capacity, and compliant recessed lift for daily workshop operations that meets the strictest safety regulations.
