This detailed description presents the technical characteristics and advantages of the Consul 0.42 S-AM BE type, 4800 mm runway length, in-ground (flush-mounted) scissor lift, which is ideal for lifting vehicles and for wheel alignment.
The Consul 0.42 S-AM BE is a professional, electro-hydraulic lifting device specifically designed for the needs of workshops and service centers. Its design allows for level lifting of vehicles, creating ideal conditions for precise wheel alignment, while remaining flush with the floor thanks to its built-in (BE) design, ensuring an unobstructed work area.
This lift offers the highest level of functionality and safety in a modern service environment:
In-ground Installation (BE): The lift is fully installed beneath the floor, so the structure does not obstruct the workspace when the lift is not in use.
Optimized for Wheel Alignment: Specifically designed for level lifting and wheel alignment, enabling work in a fixed, horizontal position.
Integrated Turntable System: Part of the optional equipment is a receiving system equipped with a cover for a turntable that can be raised 50 mm, which facilitates the positioning required for wheel alignment.
Full-Width Adjustable Sliding Plates: The full-width sliding plates (sliding plates) located along the runways are adjustable, allowing them to flexibly adapt to different axle distances and track widths.
Pneumatic Release: When lowered, the mechanical locking brakes can be released pneumatically by pressing a push button, ensuring fast and convenient operation.
Robust Structure: The platforms are made of special rolled steel profile, guaranteeing long service life and high load capacity.
Integrated Jacking Beam Rails: Rails integrated into the runways ensure the simple and safe placement of hydraulic jacking beams.
The table below summarizes the critical technical parameters of the Consul 0.42 S-AM BE lift:
| Parameter | Value | Note |
|---|---|---|
| Part Number (SKU) | 732818 | |
| Manufacturer Number (HAN) | 500445 | |
| Category | Scissor Lifts | |
| Rated load capacity | 4.200 kg | Maximum vehicle weight |
| Lifting height | approx. 1,830 mm | |
| Lifting Time (loaded) | approx. 35 seconds | |
| Set-up width | approx. 2,260 mm | |
| Installation length | ca. 5.770 mm | |
| Power supply | 400 V / 50 Hz | Three-phase mains |
| Drive Power | 5.5 kW | |
| Fuse Protection | 20 A slow-blow | |
| Runway width | ca. 650 mm | |
| Runway length | 4.800 mm | |
| Control | Electro-hydraulic | |
| Hydraulic System | Master/Slave System | |
| Protection class | IP 54 | Dust and Splash Protection |
| Standards | DIN EN 1493, CE approval |
The lift elektrohidraulikus vezérléssel features, which guarantees reliable and precise operation. The Master/Slave hydraulic system Ensures the synchronized lifting and lowering of the two lift arms, even under heavy load.
Safety is a top priority for Consul products:
Mechanical Locking System: A 17-position mechanical locking device ensures the vehicle is held in place during lifting.
Laser Point Foot Protection: A foot protection system with acoustic feedback protects operating personnel.
Main Switch: It has a separate lockable main switch in accordance with CE regulations.
Bearing: The 20 mm thick, split fixed and sliding bearings (series galvanized) ensure the smooth movement of the runways. Optionally available for calibratable wheel alignment systems.
The 0.42 S-AM BE model is specifically optimized for collaboration with modern wheel alignment systems:
Wheel Alignment Position: The lift is capable of holding the vehicle in a fixed, horizontal level to perform adjustments.
Turntable Compatibility: The standard equipment includes covered pickup elements, which allow for the integration of turntables up to 50 mm in height.
Adjustable Sliding Plates: The large, adjustable sliding plates (full size sliding plates) allow for optimal support of the vehicle axles.
Drive-Through Version: The platforms are equipped with drive-over flaps, which facilitate the driving on and off of the vehicle.
Socket Outlet: The unit is equipped with a 230 V socket outlet for connecting workshop tools.
Optional Accessories: Numerous accessories are available for the product, such as 3D wheel alignment adapters (e.g., for Beissbarth Easy 3D), anti-slip coating (not retrofittable), drive-on and drive-off ramps (of various lengths, with rollback stop), and lighting options (LED lamps).
This Consul scissor lift is the perfect combination of reliability, high load capacity, and the precision required for wheel alignment, ensuring efficient and safe work in the long term.
