This product is a high-quality, professional-grade swivel arm base designed for an in-ground scissor lift with hydraulic cylinders, specifically developed for vehicle servicing and maintenance. The nominal load capacity of 3500 kg and the included FixLift adapters offer unparalleled flexibility and safety in the workshop environment.
This base is compatible with 2.35 MKS Optima type lifts, representing the forefront of reliable and ergonomic lifting solutions.
This swivel arm base combines the quality and innovation of the Consul product family, ensuring an outstanding user experience:
Ergonomic Arm Control: The control arm design is optimized for comfortable and fatigue-free operation, minimizing user strain.
Integrated, Adjustable Lifting Table: The system includes a built-in, continuously height-adjustable lifting table. This function in a 30 mm range allows for fine-tuning, ensuring perfect vehicle positioning.
Vertical Height Adjustment Without Transversal Shift: During lifting, the vertical movement is precise and rectilinear, without any lateral shift, which increases stability and safety.
FixLift Adapterek: The package includes FixLift adapters, which further extend the lift's compatibility and enable the safe securing of vehicles with different chassis geometries.
Excellent Quality Construction: The design is identical to the standard components with part number 432120, guaranteeing the long service life and reliability characteristic of Consul products.
Accurate technical parameters are essential for precise work. The table below details the specifications of the swivel arm base:
| Parameter | Value | Note |
|---|---|---|
| Nominal Load Capacity | 3,500 kg | Maximum safe load. |
| Lifting Height | approx. 2,185 mm | Measured from floor level. |
| Alsó Szintkülönbség | approx. 80 – 245 mm | Indicates the flexibility of the installation depth. |
| Column Distance | 1.380 mm | The internal distance of the built-in structure. |
| Lifting Range | approx. 720 – 1,315 mm | The travel range of the adjustable lifting table. |
| Compatibility | 2.35 MKS Optima | Recommended specifically for this type. |
| Accessories | FixLift adapters | Increase the versatility of the fastening. |
For easy identification and ordering, the product has the following identifiers:
Part Number (SKU): 432955
Manufacturer Part Number (HAN): 9754
Category: Kéthengeres Beépíthető Emelők
This Consul rocking arm chassis is the ideal choice for all service areas where high load-bearing, precise, and ergonomic built-in lifting systems are essential for efficient work. The FixLift adapters and the adjustable lifting table guarantee that the most diverse vehicles can be lifted safely and optimally.
