The Consul 4-post lift 4.70 SN is a robust and versatile lifting solution designed for lifting passenger cars and commercial vehicles up to 7,000 kg total weight, as well as for wheel alignment. It is especially suitable for servicing long-wheelbase vehicles thanks to its extra-long platforms. This model features an integrated 3,500 kg capacity, free-wheeling scissor lift, which significantly increases operational flexibility and efficiency.
This equipment combines reliability, safety, and precise operation, making it an ideal choice for any modern service shop.
The Consul 4.70 SN lift incorporates several advanced design elements that optimize daily workshop workflows:
Hydraulic System: Hydraulic drive running in oil with silent operation ensures a smooth and reliable lift.
Electro-hydraulic Control: Modern, easy-to-operate electro-hydraulic control system.
Operating Direction: Vehicle positioning is done in the usual, rearward direction, from the position at the left front wheel.
Safety Features:
Detachable main switch (lockable according to CE requirements).
Acoustic foot protection for safe operation.
Hydraulic tensioning cylinder.
Protection against cable slack, cable break protection, and rollback protection.
Platform Design:
The platforms are equipped with 1,000 mm long ramps, ideal for sports vehicles as well.
One platform is fully adjustable, equipped with a locking mechanism (optionally available in a roller guide version).
Integrated Wheel Alignment Capabilities:
Integrated track for the jacking beam.
Integrated free-wheeling scissor lift with extendable supports.
The free-wheeling lift operates with a Master/Slave hydraulic system for synchronized lifting.
Accessory 40 mm elastomer supports.
Pneumatic Locking: Central control for the pneumatic clamping system (8 bar pressure required).
Mechanical Locking: Locking rods placed in 100 mm increments across the entire lifting height ensure mechanical support.
Certifications: IP 54 protection class, with GS certification, compliant with DIN EN 1493 standard, bearing the CE mark.
When ordered together with the drive-on lift set, the lift is enhanced with the following functions:
Integrated, full-size sliding plates.
Turntable system (up to 50 mm height), with continuous turntable cover.
The table below details the critical technical parameters of the Consul 4.70 SN lift:
| Parameter | Value | Note |
|---|---|---|
| Rated load capacity | 7.000 kg | Total vehicle weight |
| Lifting height | ca. 1.980 mm | Maximum lifting height |
| Lifting Time (loaded) | approx. 55 seconds | |
| Set-up width | 3,505 mm | |
| Drive-up height | ca. 185 / ca. 235 (AM) mm | AM: For air suspension vehicles (optional) |
| Distance between rails | ca. 2.945 mm | |
| Power supply | 400 V / 50 Hz | Three-phase connection |
| Drive Power | 3.0 kW | |
| Fuse Protection | With 20 A slow blow fuse | |
| Oil quantity | 9 liters | |
| Rail width | 630 mm | |
| Rail length | 6,240 mm | |
| Rail distance (adjustable) | approx. 750 – 1,200 mm | |
| Overall height | ca. 2.610 mm | |
| Installation length with approach ramps | 7.360 mm | |
| Drive-over height | approx. 50 mm (SN) | |
| Lifting capacity of the free-rolling lift | 3,500 kg | |
| Lifting height of the free-rolling lift | ca. 450 mm | |
| Length of the free-rolling lift | 1,400 – 1,900 mm | Extendable support arms |
| Lifting time of the free-rolling lift | approx. 15 seconds |
SKU: 730143
HAN: 473161
Category: 4-Post Lifts
The Consul 4.70 SN lift can be flexibly upgraded according to the workshop's needs:
A separately orderable auxiliary lift with a powder-coated surface finish, which provides additional lifting possibilities under the main lift platforms.
This complete set is specifically designed for lifts equipped with a free-rolling wheel lift. Compatible with 630 mm rail width and 6,240 mm rail length.
Retrofit adapters for 3D drive-on lift sets. The set contains 2 adapters.
Special anti-slip coating for lift rails, available as a factory-installed option.
Two-piece set equipped with a roller stop. Can be used with lifts that no feature a wheel alignment device, for recessed installation.
Two-piece set with roller stop, specifically for the recessed installation of lifts equipped with a wheel alignment device.
Two-piece set with roller stop. Their length is approx. 1,000 mm.
Two-piece set with roller stop. Their length is approx. 1,500 mm.
This detailed description presents the technical parameters and wide range of applications for the Consul 4.70 SN 4-post lift, highlighting safety functions and integrated solutions required for wheel alignment.
