This detailed product description presents the special, long, swinging arm base frame for the Consul premium category inground vehicle lift system, designed for a maximum load capacity of 3500 kg and equipped with FixLift adapters. This configuration offers an ideal solution for workshops requiring high-precision, discreet, and flexible lifting options.
The swinging arm base frame for the Consul 2-cylinder inground lift belongs to the C-Line and Z-Line lift families, ensuring outstanding stability and ergonomics for vehicle servicing. Thanks to the long version of the swinging arms, wider vehicles, such as cars with longer wheelbases or light commercial vehicles, can also be comfortably positioned on the lift.
A FixLift adapters integration enables precise, stepless height adjustment, which is crucial for the safe and optimal support of vehicles with different chassis heights.
During the design process, great emphasis was placed on user comfort and efficiency:
Ergonomic Arm Control: The design of the control arms minimizes physical strain during daily use.
Integrated, Adjustable Lifting Table: The height-adjustable lift table (in 25 mm increments) ensures that the lifting arms always make ideal contact with the vehicle's lifting points.
Vertical Height Adjustment Without Transversal Shift: Lifting occurs exclusively in the vertical direction, guaranteeing that the length and position of the lifting arms remain stable during the lifting process, preventing lateral movement of the vehicle.
Lifting Arms of Different Lengths: Arm lengths differing from standard models provide flexibility in handling vehicles with different track widths and wheelbases.
The following table summarizes the critical technical parameters of the swinging arm base frame:
| Characteristic | Value | Note |
|---|---|---|
| Rated load capacity | 3,500 kg | Maximum safe load. |
| Lifting height | approx. 2,185 mm | Theoretical maximum height of the vehicle's upper point. |
| Chassis height (Bottom clearance) | approx. 80 – 245 mm | The minimum and maximum distance from floor level achievable in the inground position. |
| Distance between columns | 2,500 mm | The distance between the centers of the two lifting cylinders. |
| Lifting range | approx. 550 – 1,150 mm | The adjustment range of the lifting arms, measured from floor level. |
| Weight (approx.) | 500 kg | Net weight of the base frame and the swinging arms. |
| Compatibility | 2.35 MKK | Ideally suited for 2.35 MKK type scissor lifts (Jumping jack chassis). |
| Category | Twin Ram Inground Lifts | |
| SKU (Item Number) | 432401 | |
| HAN (Factory Number) | 9763 |
This long-arm chassis is an excellent choice for professional service centers where the aesthetic and space-saving advantages of an in-ground installation, combined with the requirement for high-precision lifting, are essential.
Space saving: Since the lift can be recessed into the floor, the service area remains completely clear when the lift is not in use, maximizing the available workshop space.
Handling Larger Vehicles: Thanks to the long swing arms and the 3500 kg load capacity, this configuration is also suitable for lifting medium-sized commercial vehicles, vans, and wider passenger cars.
Precise Positioning: The FixLift adapters and stepless height adjustment ensure that the vehicle's jacking points can be precisely aligned with the lift arms, minimizing the risk of damage.
Durability and Reliability: The quality construction of Consul products guarantees a long service life, even in intensive workshop environments.
Detailed technical information is available for the product:
This submersible, long-arm chassis combines the engineering precision of Consul with the flexibility demands of modern workshops, providing a reliable lifting platform even for the most demanding tasks.
