Die set A1 + A2 | Rivet extraction | Ø 5.2 mm

A1 + A2 Tool Set – For Removal of Self-Piercing Rivets (SPR) – Ø 5.2 mm

This detailed product description is part of the Wieländer+Schill professional body repair tool range, specifically for the XSeries – Professional Riveting Technology classified into the category. The A1 + A2 tool set is designed to provide an efficient and precise solution for the professional removal of self-piercing rivets (Self-Piercing Rivets – SPR), particularly for 5.2 mm diameter applications.

This set is an essential tool for every specialist performing high-quality, damage-free body repair work, ensuring procedures comply with OEM (Original Equipment Manufacturer) requirements.

Product ID and Main Features

Part number: 700221

Product Family: XSeries – Professional Riveting Technology

Area of application: Removal of Self-Piercing Rivets (SPR)

Target Diameter: Ø 5.2 mm

Main Function: Professional, damage-free extraction of rivets from body panels.

Set Contents and Components

The A1 + A2 tool set contains two key elements that work together to ensure the optimal removal process:

These two components are precisely sized and designed to perfectly fit 5.2 mm diameter SPR rivets, minimizing the risk of damage to the surrounding material.

Technical Details and Advantages

Wieländer+Schill tools are built for durability and precision, which is essential in modern vehicle repair where handling high-strength steel and aluminum structures requires specialized equipment.

Excellently Crafted Quality

The set components (extraction rod and plate) are made of high-quality, hardened steel, which guarantees a long service life and continuous, reliable performance even under high demand. Precision machining ensures that the tools fit the rivet geometry exactly.

Expertise in Self-Piercing Rivet Removal

The removal of self-piercing rivets (SPR) presents specific challenges, as these fasteners are generally only removable by destruction. However, this tool set, thanks to Wieländer+Schill technology, makes controlled and targeted removal of the rivet possible:

1. Precise Insertion: The 700250 A1 extraction rod penetrates the rivet core or the pre-drilled hole.

2. Controlled Force Application: The 700251 A2 pulling plate serves as a support pad on the body surface, distributing the force required for pulling, thereby preventing deformation of the plate or damage to the surrounding material.

3. Damage-Free Removal: Through the appropriate force application, the rivet can be professionally removed, preparing the surface for new joining (e.g., new riveting or welding).

Compatibility and Integration

This tool set is optimized for the XSeries professional riveting technology. Although the set is exclusively for extraction, the Wieländer+Schill system ensures seamless integration with their other tools (e.g., riveting machines) in the repair process.

Application Areas

This tool set is the ideal choice:

• Body Repair Shops: Specifically for replacing components fastened with self-piercing rivets (e.g., aluminum or high-strength steel panels).

• OEM Services: For repairs where strict adherence to manufacturer specifications is required to maintain structural integrity.

• Structural Repairs: For any situation where the rivet connection needs to be dismantled for the replacement of a damaged component.

Quality Assurance and Standards

Wieländer+Schill is committed to the highest quality, which is supported by certifications:

• ISO 9001: Quality Management System Certificate.

• ISO 14001: Environmental Management System Certificate.

These standards guarantee that the manufacturing and quality control of the tool set with part number 700221 meet even the strictest industry requirements.

Summary of Technical Data

This tool set is an indispensable element of professional body repair, ensuring fast, efficient, and professional work in the case of vehicles made with SPR technology.
