The Magido L102 industrial washing machine is an excellent quality, stainless steel cleaning device specifically designed for the efficient and reliable washing of medium-sized machine parts. With a combination of hot water and the appropriate detergent, this Lavatronix series machine offers an ideal solution for numerous industrial applications where hygiene and precise cleaning are essential.
The robust SS304 stainless steel construction of the machine guarantees a long service life and corrosion resistance, allowing its use in various industrial environments. The cleaning process is ensured by a rotating basket driven by water pressure, which enables uniform and thorough cleaning of all surfaces.
Excellent Cleaning Performance: Two high-performance pumps ensure optimal spray pressure and effective detergent distribution.
Robust Design: Fully SS304 stainless steel construction resistant to corrosion and harsh detergents.
Automated Operation: The rotating basket is driven by water pressure, which simplifies handling.
Safety Features: Includes low water level protection as standard equipment, which protects the heating element and pumps from damage.
Flexible Timing: The built-in timer allows setting washing cycles between 0 and 60 minutes.
The specifications of the Magido L102 industrial washing machine ensure high-capacity and reliable operation:
| Parameter | Value | Note |
|---|---|---|
| Category | Workshop Equipment | |
| Brand | Magido | Lavatronix series |
| Sub-category | Industrial washing machines | |
| Basket Diameter (Ø) | 910 mm | Ideal for medium-sized parts |
| Maximum Load Capacity | 200 kg | Simultaneous cleaning of a large quantity of parts |
| Connection Voltage | 400V, 3 phase | Industrial network requirement |
| Total Connected Power | 7.8 kW | |
| Heater Power | 6 kW | For fast and efficient water heating |
| Tank Capacity | 175 liters | |
| Pump Power | 2 x 110 liter/min | Total flow rate 220 liter/min |
| Spray Pressure | 2.5 bar | Powerful cleaning effect |
| Temperature Setting | 0–60° C | Variable temperature depending on the type of contamination |
| Timer Range | 0–60 min | Programmable washing time |
| Material | SS304 Stainless Steel | Excellent Corrosion Resistance |
| Loading Height | 490 mm | Easy access to the basket |
| Dimensions (With Closed Door) (mm) | 1250 x 1250 x 1400 (W x D x H) | Compact footprint |
| Dimensions (With Open Door) (mm) | 1230 x 1295 x 1990 (W x D x H) | Space required for operation |
The flexibility of the Magido L102 washing machine is further enhanced by optional accessories that allow the equipment to be customized for specific cleaning requirements:
Oil Skimmer: This feature is essential for parts handled with greasy or oily contaminants. The oil skimmer continuously removes oil floating on the surface of the water, preventing its return to the surfaces being cleaned, and extends the life of the cleaning fluid.
Motorized Basket Drive: Although the basic model drives the basket using water pressure, the motorized drive ensures more precise speed control and more constant rotation, which can be advantageous, especially when cleaning highly sensitive components.
Removable Basket with Trolley: For ease of handling, the basket has a removable design and can be moved with an accompanying trolley. This significantly simplifies loading and unloading large or heavy parts, as well as cleaning the basket itself.
The Magido L102 industrial washing machine is ideally suited for applications in the following areas:
Vehicle Service Centers: Preparation of engine blocks, cylinder heads, gearbox housings, and other large, oily components for overhaul or repair.
Manufacturing Plants: Degreasing and cleaning of tools, jigs, and production line parts.
Metal Processing Industry: Removal of machining residues, coolants, and swarf.
The temperature control between 0-60°C allows for careful cleaning of heat-sensitive materials, while higher temperatures effectively dissolve stubborn greases and oils. The pump capacity of 2 x 110 l/min guarantees that the cleaning agent reaches every corner.
This Magido L102 model offers a combination of reliability, high capacity (200 kg load capacity), and the durability of stainless steel for professional cleaning tasks.
