Jack Weigh EZ RFX® Kit for Aircraft Weighing

Intercomp Ultra-Portable Load Cell Kit (Jack Weigh Kit)

The Intercomp Ultra-Portable Load Cell Kit is a precision measuring device developed for the aerospace industry, enabling the extremely accurate determination of aircraft weight and center of gravity. This system is ideal for performing weight and balance calculations, ensuring safe and compliant operation. Thanks to its portability and robust design, this kit is equally suitable for use in workshop environments and remote locations.

Key Features and Advantages

This load cell kit provides the highest level of accuracy and reliability for determining aircraft center of gravity.

• Exceptional Portability: Thanks to its compact design, the kit is easily transportable and installable, minimizing on-site setup time.
• High Accuracy: Advanced sensor technology guarantees the reliability of measurement data, which is essential for aircraft weight and balance calculations.
• Robust Construction: Components meeting industrial standards ensure long service life and reliable operation even under extreme conditions.
• Wireless Communication (Optional): When paired with modern displays and software, it allows for wireless data transfer, increasing flexibility during the weighing process.
• Broad Compatibility: Specifically designed for determining the center of gravity of aircraft, ideal for small and medium-sized air vehicles, but adaptable to larger capacity systems with the appropriate configuration.

Technical Specifications

Intercomp Jack Weigh Kits are available in various configurations that can be tailored to user requirements. The table below summarizes the main available systems and their characteristics.

Compatible Accessories and Software

For maximum efficiency, the load cell kits can be integrated with Intercomp's advanced display and software systems:

• TAC30™ CPU – Touchscreen Indicator: Provides an intuitive user interface for fast and accurate processing of weight data.
• RFX® Wireless Handheld Indicator: Allows the operator to monitor load data in real time, even away from the measuring points.
• RFX® Wireless AC100™ Aircraft Scale CPU: Wireless central unit specially optimized for AC100™ systems.
• ACWeigh™ Software: Software developed for aircraft weight and balance calculations, which simplifies documentation and conformity verification.
• iACWeigh™: Application optimized for mobile devices for weight data management.

Application Areas in Aviation Technology

Intercomp Jack Weigh systems play a crucial role in several areas of aircraft operation:

1. Weight & Balance Calculations: The most important application, where the determined weight point based on precise axle and wheel measurements is essential for safe taxiing and flight.
2. eVTOL Development: Precise measurement of the weight distribution of new generation electric vertical take-off and landing vehicles (eVTOL) during the prototyping phase.
3. Capacity Check: Checking the maximum allowable weight of aircraft with different load capacities (low, medium, and high capacity).
4. Military Applications: Weighing of military aircraft, where compliance with strict regulations is of critical importance.

Calibration and Support

To maintain measurement accuracy, Intercomp offers comprehensive system support and calibration services:

• CSM™ Manual Test Stand: Basic tool for manual checking and calibration of load cells.
• CSA™ Automatic Test Stand: Automated system ensuring greater efficiency for regular calibration procedures.

This Ultra-Portable Scale Kit reflects Intercomp's commitment to precision measurement, ensuring the highest level of flight safety for users.
