IntercompWeigh™ Software – The Solution for Intelligent Management of Measurement Data
IntercompWeigh™ Software is an advanced software solution that maximizes the performance and efficiency of Intercomp precision weighing systems. This platform is a key tool for anyone requiring reliable, detailed, and easily manageable data acquisition, storage, and analysis for various measurement applications – whether it's truck weighing, aircraft weight and balance calculation, or industrial process monitoring.
The IntercompWeigh™ software can be integrated with the wide range of Intercomp weighing instruments, ensuring seamless data transfer and real-time feedback. The goal of the software is to instantly convert raw measurement data into usable, standardized reports, thereby supporting precise decision-making and regulatory compliance.
Key Features and Advantages
The IntercompWeigh™ software package is designed to meet the strictest industrial and regulatory requirements while providing a user-friendly interface for complex operations.
Comprehensive Data Management and Recording
- Real-Time Data Acquisition: Provides a direct connection to connected Intercomp measuring instruments (indicators, display units), enabling immediate recording of weight data.
- Customizable Data Fields: It is possible to define custom fields (e.g., order number, vehicle ID, operator name), which simplifies data interpretation.
- Automatic Logging: Every measurement is automatically recorded with a timestamp and serial number, ensuring comprehensive event logging.
Flexible Application Areas
The modular structure of the software enables cooperation with various Intercomp weighing systems:
- Vehicle Weighing: Supports static weighing and Weigh-In-Motion (WIM) measurements, ideal for traffic control and inspection purposes.
- Aerospace Applications: Plays a critical role in weight and balance calculations, supporting data from TAC30™ CPU and RFX® displays.
- Military and Special Applications: Complies with military standards during vehicle and aircraft weighing.
Report Generation and Export
- Standard and Custom Reports: Predefined templates are available (e.g., gross weight, axle load distribution), as well as the option to compile custom reports according to user requirements.
- Data Export: Data can be easily exported into standard industry formats, such as CSV, Excel, or PDF, facilitating integration into other enterprise resource planning or analysis systems.
User Interface and Compatibility
- Intuitive User Interface: The software offers a user-friendly graphical interface (GUI), minimizing the learning curve.
- Compatibility: Optimized specifically for synchronization with Intercomp displays and data acquisition units.
Technical Specifications and Compatible Hardware
The performance of the IntercompWeigh™ software largely depends on the connected hardware devices. The table below summarizes the main weighing system categories supported by the software and the corresponding displays.
| Category |
Example Hardware Devices |
Main Function |
| Vehicle Weighing Systems |
LS630-WIM™, LS-WIM®, LP600™, AX900™ |
Static and dynamic weight and axle load measurement. |
| Aviation Weighing Systems |
AC15-LP™, AC40-LP™, Jack Weigh AC100™ Kit |
Determination of the center of gravity (W&B) of aircraft. |
| Displays and CPUs |
TAC30™ CPU (Touchscreen), RFX® Wireless Handheld Indicator |
Data processing, display, and software connectivity. |
| Special Systems |
ITS/Highway Enforcement WIM Sensors, Military PT300™ |
Highway enforcement, data acquisition in special environments. |
Software Compatibility Details
The IntercompWeigh™ software is capable of processing data generated by the following software and display platforms:
- ACWeigh™ Software: Primarily for processing weight data related to aviation platform scales and lift weighing kits (Jack Weigh Kits).
- iACWeigh™: A mobile or tablet application that likely offers a simplified, portable version of the center of gravity calculations.
- Displays: Direct communication with the TAC30™ touchscreen CPU, which serves as the central unit for the weighing process.
Data Integrity and Security
The software ensures the integrity of the measurement data throughout the entire process:
- Data logging: Data arriving from the display unit (e.g., RFX® or TAC30™) is immediately recorded.
- Validation: The software can verify the validity of incoming data based on the set calibration parameters.
- Archiving: The data is securely stored in a local or network database.
Detailed Description of Application Areas
Due to the flexibility of the IntercompWeigh™ software, it can be used in several critical industries:
1. Road Transport and Logistics
The software is ideal for the efficient and precise weighing of road traffic.
- Overload Prevention: Working together with the LS-WIM® and LS630-WIM™ systems, it enables the measurement of vehicle axle loads in motion, providing immediate alerts for overloading.
- Logistics Terminals: It facilitates the documentation of the precise weight of cargo at loading and unloading points, optimizing capacity utilization.
- ITS/Authority Checks: Quick data export simplifies the preparation of authority logbooks.
2. Aviation Technology and Maintenance
Determining the aircraft's center of gravity (Weight & Balance) is vitally important for safe operation.
- Center of Gravity Calculation: With the help of the ACWeigh™ and iACWeigh™ functions, it automatically calculates the aircraft's center of gravity from the data of platform scales (e.g., AC60-LP™) or lifting scale sets.
- Easy Documentation: The software generates the necessary weight reports, which certify compliance with airworthiness requirements.
3. Agriculture and Feed Production
Although the software's main profile is in vehicle and aviation technology, it can also be integrated with in-vehicle weighing systems (e.g., for TMR mixers).
- Recipe Tracking: Precise data recording on the composition and quantity of mixed feed, ensuring optimal nutrition for livestock.
Summary
The IntercompWeigh™ Software is not just a data collection tool; it is a comprehensive solution for managing measurement data, increasing accuracy, reducing administrative burdens, and ensuring compliance with strict industry regulations. Its wide-ranging hardware compatibility and user-friendly interface make this software an essential accessory for Intercomp weighing systems.
