Part number: 311063
This product is a precision temperature indicator pencil designed to reliably signal the achievement of surface temperature during industrial applications. The temperature indicators are marking devices with a calibrated melting point, essential for the accurate monitoring of heat treatment processes.
Temperature indicator pencils contain a marking material with a specific, calibrated melting point. When the marked surface reaches the pencil's nominal temperature, the mark clearly melts (flows away), visually indicating that the critical temperature has been reached.
This green marking pencil is specifically for 204 °C precise temperature detection.
Precise Temperature Indication: The melting of the mark reliably indicates that the set temperature has been reached.
Magas Pontosság: compared to the nominal temperature, only a +/- 1% deviation in measurement accuracy.
Simple Application: The workpiece must be marked before or during heating. The melting of the mark provides immediate, visual feedback.
Ideal Surfaces: Suitable for determining the temperature of specifically smooth surfaces.
This 204 °C temperature indicator pencil is an ideal choice for monitoring numerous critical industrial processes, especially in cases where maintaining the temperature within a strict range is essential for quality assurance and safety.
The application areas of the marking pencil include:
Welding and Metal Processing: Temperature control before or after welding seams.
Preheating: Verification of preheating metallic materials to the optimal temperature before welding.
Intermediate Storage: Monitoring temperature stability between phases of heat treatment.
Heat treatment after welding: Monitoring the temperature profile of stress-relieving or post-hardening heat treatments.
Annealing (Soft Annealing): Execution at the temperature corresponding to the metal annealing process.
Stress Relief Annealing: Confirmation of the heat treatment temperature required to eliminate internal stresses.
The physical and performance characteristics of the product are as follows:
| Property | Value |
|---|---|
| Product Type | Temperature indicating crayon |
| Nominal Temperature | 204 °C |
| Color | Green |
| Part number | 311063 |
| Pontosság | +/- 1% compared to the nominal temperature |
| Application Surface | Smooth surfaces |
| Operating Principle | Melting indication |
| Length | 136.16 mm |
| Width | 11.86 mm |
| Höhe | 11.86 mm |
In addition to the 204 °C indicator, the product family covers other temperature ranges, ensuring comprehensive temperature monitoring:
| Part number | Color | Nominal Temperature |
|---|---|---|
| 311062 | Red | 100 °C |
| 311063 | Green | 204 °C |
| 311064 | Yellow | 400 °C |
| 311065 | Blue | 500 °C |
These accessory products (100 °C, 400 °C, and 500 °C) operate on the same principles and are equally suitable for temperature control in industrial and welding applications on smooth surfaces.
This temperature indicating crayon is part of the Wieländer+Schill professional tool range, which meets the highest quality and precision requirements in the body repair and metal processing sectors. Using the product minimizes the risk of heat treatment errors and guarantees the correct thermal condition of the workpieces.
