The Wieländer+Schill D13 removal pin (part number: 700812) is a premium quality tool developed for professional automotive body repair technologies, belonging to the XSeries – Professional Riveting Technology product line. This specialized tool is essential for the reliable and efficient removal of Self Piercing Rivets (SPR), ensuring the damage-free replacement or repair of body panels.
This removal pin is specifically optimized for the precise and controlled removal of self-piercing rivets of the given size, minimizing the risk of damage to surrounding material. Wieländer+Schill tools are renowned for their durability and precision, guaranteeing a long service life and consistent performance even under the most intensive workshop conditions.
The D13 removal pin is a precisely machined component designed to perfectly match self-piercing rivets, enabling their safe and efficient extraction from the body structure.
Main application areas:
Self-Piercing Rivet Removal: Only usable for self-piercing rivets with a diameter of 5.3 mm and a length of 7.5 mm.
Body Repair: Ideal for repairing modern vehicles where riveted joints are essential for joining high-strength materials (e.g., high-strength steels).
Professional Use: Specially tailored to the needs of workshops and authorized service centers where speed and quality are paramount.
The design of the tool ensures that the pin remains firmly seated in the rivet during the extraction process, minimizing the chance of slippage or damage to the tool. Manufactured with precise tolerance limits, the pin guarantees the complete and damage-free removal of the rivet from the workpiece.
The D13 removal pin is manufactured according to strict quality specifications, ensuring reliable operation.
| Property | Value | Note |
|---|---|---|
| Part number | 700812 | Unique identifier for the set and for ordering. |
| Product Name | D13 Removal Pin | Extraction mandrel for Self Piercing Rivets |
| Compatible Rivet Diameter | 5.3 mm | Optimal fit of the pin for this diameter. |
| Compatible Rivet Length | 7.5 mm | The length and design of the pin are adapted to this size. |
| Total Length (L) | 18 mm | The total length of the tool. |
| Width (W) | 14 mm | The width dimension of the tool. |
| Height (H) | 30 mm | The height dimension of the tool. |
| Product Family | XSeries – Professional Riveting Technology | The premium class riveting tool series from Wieländer+Schill. |
| Application | Self-Piercing Rivet Removal | Special Function. |
The use of the D13 removal pin brings several advantages during the body repair process:
Precision and Control: The precise design of the tool guarantees that force is applied only to the rivet during removal, protecting the surrounding metal structure from damage, which is particularly important for high-strength and sensitive materials.
Efficiency: Enables fast and reliable removal, reducing repair time and increasing workshop productivity.
Durability: Wieländer+Schill tools are made from excellent quality materials, resisting high mechanical stress and frequent use.
System Compatibility: Can be perfectly integrated into the Wieländer+Schill XSeries riveting systems and connected to the appropriate riveting tools (e.g., hydraulic or electric riveting guns).
Wieländer+Schill is committed to the highest quality standards. Manufacturing processes undergo strict quality control, which is also supported by external certifications:
ISO 9001: Quality Management System certification, which guarantees consistently high product quality.
ISO 14001: Environmentally focused management certificate reflecting sustainable manufacturing practices.
These certificates ensure that the D13 extraction pin is not only efficient but also a reliable and responsibly manufactured tool.
The D13 pin is part of the broader Wieländer+Schill product range, which covers the entire riveting technology (tools, setting heads, extraction pin sets) and other areas of body repair (e.g., welding technology, demounting tools). This modular approach allows workshops to source all necessary tools for complex body work from a single, reliable source.
Selecting the correct extraction pin is a critical step when replacing a rivet. Using a pin of the wrong size or quality can lead to damage to the rivet head, deformation of the workpiece, or premature wear of the tool. The D13 (700812) is specifically calibrated for 5.3 mm / 7.5 mm SPRs, ensuring a perfect fit and minimal resistance during extraction.
This tool is the ideal choice for any professional who demands the highest level of precision and reliability during structural repairs of vehicles.
