The ACWeigh™ software is a robust data management and analysis tool developed by the Intercomp group, specifically optimized for aircraft weighing systems (platform scales and jack weighing kits). This software ensures the accuracy of Weight & Balance calculations, digitizes measurement processes, and efficiently manages the storage and analysis of aircraft weight data.
The goal of ACWeigh™ is to make the collection, processing, and documentation of aircraft measurement data simple, fast, and verifiable for compliance, thus supporting safe operations and efficient maintenance processes.
The ACWeigh™ software offers several key features that significantly improve the efficiency and reliability of measurement workflows:
Integrated Data Acquisition: Direct communication with Intercomp wireless (RFX®) or wired indicators, ensuring immediate and error-free transfer of measurement data.
Aircraft Database Management: Allows for the storage and management of various aircraft types and their fundamental weight and balance parameters (e.g., empty weight, CG positions).
Weight & Balance Calculations: Automatic calculations based on measured wheel or jack point weights, immediately displaying the vehicle's Center of Gravity (CG) and its position within the allowed limits.
Logging and Documentation: Detailed logging of every measurement event, including date, time, measuring device used, and measurement results. This is essential for regulatory compliance and audits.
User-Friendly Interface: Intuitive Graphical User Interface (GUI) that minimizes learning time and reduces the possibility of human error during complex calculations.
Compatibility: Wide compatibility with Intercomp aircraft weighing equipment, including the TAC30™ touch screen indicators and RFX® wireless systems.
The ACWeigh™ software is designed for modern data management needs, ensuring seamless integration with existing Intercomp hardware devices.
| Parameter | Detail |
|---|---|
| Software Purpose | Aircraft Weight & Balance (W&B) Data Collection and Analysis |
| Compatible Hardware | Intercomp Platform Scales (AC15-LP, AC40-LP, AC60-LP, AC30-60, ACII™) |
| Compatible Hardware | Intercomp Jack Weigh Kits (AC100™, EZ RFX®) |
| Compatible Displays | TAC30™ CPU (Touch Screen Indicator) |
| Compatible Communication | RFX® Wireless Technology |
| Database Management | Aircraft types, configurations, measurement presets |
| Output Formats | Exportable reports (e.g., PDF, CSV) |
| Application Areas | Maintenance and operation of commercial, military, and private aircraft |
The flexibility of the ACWeigh™ software allows users to apply it across the most diverse segments of aviation:
When the aircraft is placed directly onto platform scales (e.g., AC60-LP™ or ACII™ systems), the ACWeigh™ software enables the following:
Accurate Axle Weight Recording: The software accepts the individual weight values for the main gear and the nose gear (or tail wheel).
CG Position Calculation: Based on the input data, it immediately determines the longitudinal and lateral position of the center of gravity.
Limit Value Checking: It compares the calculated CG in real-time against the permissible limits recorded in the aircraft's weight and balance charts, providing a visual indication of any exceedances.
When using jack weigh kits (such as AC100™ or EZ RFX®), where the aircraft is jacked up and the weight at each jacking point is measured:
Jacking Point Weight Management: The software manages the measurement of weights at four (or more) jacking points, taking into account the geometric setup of the jacking arms.
Total Weight and CG Determination: The software extrapolates the total aircraft weight and the center of gravity location from the measured point weights, which is critical for high-capacity aircraft.
The software is indispensable not only for daily operational weighing but also for technical maintenance:
Calibration Data Storage: Recording the test weights and the results of calibration procedures used to calibrate the scale systems. This supports the CSM™ Manual Test Stand or CSA™ Automatic Test Stand archiving of data generated by.
Component Replacement Tracking: Allows documentation of re-weighing after the replacement of heavy components, ensuring the aircraft's weight data remains up-to-date.
The ACWeigh™ software is also prepared to handle modern aerospace challenges:
eVTOL Development: Supports the weighing requirements for new generation electric vertical take-off and landing (eVTOL) vehicles, which often have varying weight distributions.
Low Profile Systems: Compatible with low profile scales (e.g., AC15-LP), which are ideal for special on-site weighing needs.
The ACWeigh™ software is an integral part of the complete Intercomp weighing instrument ecosystem. Users can utilize the following accessory devices offered by Intercomp along with the software:
RFX® Wireless Displays: RFX® technology ensures the secure and fast transfer of weighing data from the scale platforms to the ACWeigh™ software running on the computer, eliminating the limitations caused by cables.
TAC30™ CPU: This touch screen indicator is capable of performing basic calculations independently, but when synchronized with the ACWeigh™ software, it provides deeper analysis and archiving capabilities.
iACWeigh™: The iACWeigh™ mobile application can complement the desktop software, enabling data logging and verification on mobile devices as well, although ACWeigh™ offers the full, centralized data management solution.
Thus, the ACWeigh™ software is not just a weighing program, but a comprehensive solution for managing flight weight data that increases safety, optimizes maintenance cycles, and ensures compliance with strict regulatory requirements.
