OCIO – CONTINUOUS TANK LEVEL MONITORING FOR FUEL AND OIL

OCIO is a tank level indicator for fuel and oil that detects the static pressure generated by the fluid height by means of a tube inserted into the tank and displays the fluid level or volume.

The system consists of:

• A control unit for displaying the level and managing the system. The unit is equipped with an intuitive, complete software and permits the connection of two alarm or lock devices.
• A tube for detecting static pressure: The tube end is inserted from the top of the tank and lowered down into the liquid until it touches the bottom.

The software is used to:

• Set tank dimensions and type
• Define indication level
• Define alarm levels
• Calibrate the instrument
• Define measurement unit

In base of on the set alarm levels, the control unit deactivates or activates the contact by acting as a remote switch for starting the alarms or cutting power to the connected equipment.

• Probe tube length: 10 m.
• Maximum measurable height: 4 m.
